Equipment Description

FLUSHBY OIL WELLS FLUSING AND CLEAN OUT TRUCKS NEW UNUSED KEPT WAREHOUSED
We will still get all the equipment and entire truck inspected and the mast will be recertified to LEVEL 4 for oilfield applications. 54’ free standing mast, 65’ 11” crown to ground. 65,000 lbs static hook load vertical and 50,000 lbs static hook load slant work. See below for the rest of the build specifications from 2015 when the unit was completed.

? Gardner Denver, TEEF 4X5, Triplex Pump c/w Coors #10 steel valves, 6” suction manifold.
? High pressure piping threaded c/w Oteco relief valve (Neutron Valves)
? 450HP 1:1 ratio two shaft split box c/w air shift
? 4:1 ratio chain case assembly c/w splined input shaft
? Drive-lines fabricated & balanced to accommodate split box and chain case
? Esso Gear 75W90-GX Extra oil for split box, chain case & triplex
? Bowie three inch (3”) nitrile geared pump & hydraulic drive package, grease manifold,
drip tray mounted on passenger side.
? Bowie controls at rear control panel
? Chelsea eight bolt Power-take-off c/w air shift
? Hydraulic wet kit c/w pumps, filter, piping, hoses, fittings and oil
? Power tong/BOP circuits
? Two (2) SJ100 hydraulic rear leveling jacks c/w controls & jack stands
? Split nuts for SJ100
? Operators control panel c/w standard controls/gauges
? HL-25-7-86-3-559 Pullmaster hydraulic winch c/w two speed rapid reverse
and 3/4” groove drum (large drum)
? 3/4” cable for HL25 winch – 350 feet
? Pullmaster PL5 auxiliary winch
? 3/8” cable, chain and hook for auxiliary winch
? Fifty-three (53ft) Flushby mast rated at 65,000# hook load vertical and 50,000# slant
? Slant tray in mast (Square)
? Two (2) hydraulic mast raising cylinders
? Slant arm package c/w controls
? Two sheave crown assembly for 3/4” wire rope
? Custom fabricated A-Leg assembly
? Engineer’s Certification and Inspection
? 65,000 # single sheave traveling block (Heavy Duty)
? Custom fabricated headache rack assembly
? Over cab cable protector
? Cable anchor bar for slip program
? Rear bumper boxed c/w tow hook
? One (1) cabinet tool box c/w doors at each end, light and heater mounted behind cab across frame
? Two (2) aluminum tool boxes, mounted RH and LH rear (drawers in LH box)
? One (1) varsol tank large with dry compartment –near Bowie as room permits
? Pail holders as room allows
? Standard light package c/w back-up alarm
**THIS IS NOT EXPLOSION PROOF**
? Rod BOP c/w hand pump and 25Ft. fire-guard BOP hose (BOP mount)
? Working floor adjustable for multiple working heights and ladder
? Fall arrestor safety device c/w certified mounting block.
? One (1) 25 ton Trico rod hook
? Two (2) 25 ton Trico rod elevators c/w (4) -1” and plates and screws
? One (1) 25 ton 1 ¼” plate type elevator c/w (2) 1 ¼” plates and screws
? Two (2) ¾” x 7/8” rod wrenches
? Two (2) 1” rod wrenches
? Trico rod spinner
? Ground reel and cable
? Fire extinguisher (2) 30 # ABC Type
? Emergency warning system
? Hydraulic weight indicator
? Advance Aluminum Tank – 1.5m3 hydraulic/ 9m3 product Code TC406 Crude
? Mounting plate and rest for hydraulic picker
? 3” suction hose
? 1 1/2” 5000# pressure hose
? Electronic Titan tank level gauge (installed)
? Electronic pressure gauge
? Electronic counter totalizer
? Sandblast and paint – 2 standard colors (chassis cab not included
Pricing will be including level IV inspection, commercial vehicle inspection, tank inspection, safety and oil changes for split shaft PTO, chain case, winches and triplex is below.

Serious cash ready to purchase buyer please send us your complete specifications and well locations where you want to use these trucks so we can better serve your needs. EMAIL: sales543@tubularking.com

Beside this we have full line of OCTG pipes tubulars, LINE PIPE coated or uncoated in all grades weights and lot more send us your valued enquiries by email. Visit us at www.tubularking.com

Equipment Gallery
